AMD Ryzen 7 9800X3D 8 Core/16 Thread AM5 CPU No Fan

Harness the ultimate gaming edge with AMD Ryzen™ 7 9800X3D Processor. Enjoy faster gaming with 2nd gen AMD 3D V-Cache™ technology for low latency.



Name
AMD Ryzen 7 9800X3D

Series
Ryzen 9000 Series

AMD Pro Technologies
No

Processor Architecture
Zen 5

Number of CPU Cores
8

Multithreading (SMT)
Yes

Number of Threads
16

Max Boost Clock
Up to 5.2 GHz

Base Clock
4.7 GHz

L1 Cache
640 KB

L2 Cache
8 MB

L3 Cache
96 MB

Default TDP
120W

Processor Technology for CPU Cores
TSM 4nm FinFET

Processor Technology for I/O Die
TSMC 6nm FinFET

Package Die Count
2

Unlocked for Overclocking
Yes

AMD Expo Memory Overclocking Technology
Yes

Precision Boost Overdrive
Yes

Curve Optimizer Voltage Offsets
Yes

AMD Ryzen Master Support
Yes

CPU Socket
AM5

Supporting Chipsets
A620 , X670E , X670 , B650E , B650 , X870E , X870 , B840 , B850

CPU Boost Technology
Precision Boost 2

Instruction Set
x86-64

Supported Extensions
AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64

Thermal Solution (PIB)
Not Included

Recommended Cooler
Liquid cooler recommended for optimal performance

Max Operating Temperature (Tjmax)
95°C
